Advertising Machine
Raspberry PI Board
High Definition Multi-
media Interface Board
With the rapid development of science and technology, industrial intelligence has become an important force to promote the transformation and upgrading of the industrial industry. Industrial intelligence can achieve design, research and development, improve production efficiency, reduce production costs and improve product quality through digital, mobile and intelligent technology. Industrial intelligent solution is an industrial intelligent system based on intelligent data perception, big data integration, analysis and intelligent control to provide customers with solutions.
Features
HDMI board could output videos with high-definition and it can transmit digital audio with high efficiency. It is convenient to connect with other devices and easy to plug and remove. It provides convenient, high-quality multimedia output solutions for a variety of application scenarios.
High-definition Video Output
HDMI boards provide high-definition video output, support a variety of resolutions and video formats, including standard HD (720p), full HD (1080p) and higher resolution formats.
Digital Audio Transmission
In addition to video signals, the HDMI board also supports digital audio transmission, which can transmit high-quality audio signals through the same cable, supporting a variety of audio formats and channel configurations.
Easy to Connect
HDMI interface is a common digital interface standard, so the HDMI board can be easily connected to a variety of external display devices, including TVS, monitors, projectors, etc. And there is no need to put additional converters or adapters are required.
Easy to Plug and Pull
HDMI interfaces usually adopt standardized plug and jack designs, making the connection and disconnection process very easy and users do not need to care about polarity or direction.
Integrated Audio and Video Transmission
HDMI board can simultaneously transmit video and audio signals, simplify the wiring and setup process and provide a convenient multimedia output solution.
Multi-function
Some HDMI boards also have other functions, such as audio output, speaker interface, USB interface, etc., to meet the needs of different scenarios.
Wide Compatibility
HDMI is a universal digital interface standard, so HDMI boards usually have a wide range of compatibility and can be connected and used with a variety of computers, single-board computers, embedded systems and other devices.
TECHNICAL
SPECIFICATIONS
| Touch Function
Support USB touch input |
| Upgrades
Support USB flash drive local upgrade |
| Button Remote Control Function
Support 5V,12V screen power supply |
| Main Board Power Supply
Support 12V,2.0mm Dc plug and 4-pin 2.0 socket |
| Serial Port
Supports 1 TTL serial port and uses 4-pin 2.0 socket |
| HDM12.0
Supports 1 HDM2.0 input, maximum resolution 3840X2160/60Hz |
| Dp interface
Supports 1 Dp 1.2A input,maximum resolution 3840X2160/60Hz |
| HDMI1.4
Supports 2 HDMl1.4 input, maximum resolution of 3840X2160/30Hz |
| Power Amplifer Output
Support 2.0 power amplifier output, using 4-pin 2.0 socket, maximum output power up to 2*8euro /8W |
| USB
USB 2.0 for motherboard software upgade, can not be used for other purpose. USB 2.0 for touch output,connects to internal USB 2.0 |
| Earphone
Supports one 3.5mm earphone output. After the earphone is connected, the power amplifer is silent and no sound output is available at the same time |
| Backlight Control
1 way backlight control interface,using standard 6-pin 2.0 socket; support PWM dimming and DC dimming, male board, the default is DC dimming.Change this when PwM diming is reouired |
| Button Remote Control Function
Support remote control and key function, remote control using 3-pin 2.0 socket, key using 10-pin 2.0 socket. Default 5 keys (6 or 7 keys optional) |
| V-by-one
Supports 1-way 8-lane V-by-one output, adopts patch 51-pin FPC seat. can directly point4K screen, the maximum supports resolution can reach 3840*2160/60Hz.And the screen can be rotated 90 degrees /180 degrees/270 degrees |
Application
HDMI board (or HDMI module) is a hardware module or circuit board specially used to achieve HDMI interface functions, often used in various devices that need to integrate HDMI functions. The following are the main aspects of HDMI board applications:
Consumer Electronics
TVS and Monitors
HDMI boards are used in TVS and monitors to implement HDMI input interfaces to receive and display high-definition signals from external devices.
Game Console
Built-in HDMI board for output of high quality game picture and audio to the monitor or TV.
Media Players
such as Blu-ray players, streaming media devices, etc., use HDMI boards to output high-definition audio and video.
Computers and Peripherals
Laptops and Desktops
Built-in HDMI board for HDMI output and can be connected to an external display or projector.
Video Card
The HDMI board on the video card is responsible for the output of images and sound signals to the display.
Portable Devices
such as tablets and smartphones, connected to external display devices via HDMI boards for projection.
Professional Audio and Video Eequipment
Video Conferencing System
The HDMI board is used to connect the camera, display and audio equipment to provide high-definition audio and video transmission.
Broadcast and Recording Equipment
Professional cameras and recording equipment use HDMI boards to transmit high-definition signals to displays or storage devices.
Home and Business Entertainment Systems
Home Theater
The HDMI board implements multiple HDMI inputs and outputs in the AV receiver, connecting various audio and video devices.
Digital Signage
Digital signage in public places uses HDMI boards to drive displays and play advertising and informational content.
Industrial and Medical Equipment
Industrial Display Systems
Industrial monitors and control systems use HDMI boards to display high-resolution surveillance video or data.
Medical Imaging Equipment
Medical imaging equipment transmits high-definition images to the display via HDMI boards for diagnosis and analysis.
Educational Equipment
Teaching Whiteboard
Electronic whiteboard uses HDMI board to connect computer and display device to achieve interactive teaching.
Projector
HDMI board is used in the projector to achieve high-definition connection with computers and other devices.
Cars and Transportation
In-car Entertainment Systems
HDMI boards are used in in-car entertainment systems to connect mobile devices or media players to play videos and music.
Navigation and Monitoring Equipment
In-vehicle navigation and monitoring equipment uses HDMI boards to transmit and display video signals.
Develop and Test Equipment
Development Board: HDMI development board is used for the development and testing of embedded systems, and provides HDMI interface functions.
Test Instruments: HDMI signal testers and analyzers use HDMI boards to test and analyze the quality and characteristics of HDMI signals.
Virtual and Augmented Reality Devices
VR/AR Headsets
HDMI boards are used in VR/AR devices to achieve high-definition signal transmission and provide an immersive experience.
Multimedia
Interactive System
Exhibition and Interactive Display HDMI boards are used in interactive exhibition systems to connect display devices and play multimedia content.
In addition, we offer a variety of HDMI board models for you to choose to meet your different needs. In addition to standard models, we also offer customized services to meet your specific functional needs. Whether you need specific input/output ports, resolution support, audio capabilities or other customized functions, we can tailor the design to your requirements. Our goal is to provide you with the solution that best meets your needs and ensures that your equipment performs at its best. Please feel free to contact us and let us discuss how to customize the HDMI board to meet your needs.
